51.2V LiFePO4 Battery Pack 6000 Cycles Rack Lifepo4 Battery Module

Ask Lasest Price
Brand Name :	FUNPACK
Model Number :	FP05-4U
Certification :	MSDS UN38.3
Price :	Negotiated The Price
Payment Terms :	T/T, D/P, D/A, L/C
Supply Ability :	30PCS /Month
Delivery Time :	30-45 work days

Add to Cart

Product Details
Company Profile

51.2V LiFePO4 Battery Pack 6000 Cycles Rack Lifepo4 Battery Module

Product Description Of LFP Energe Storage Battery:

This battery module integrated with intelligent BMS inside, has big advantages on safety, cycle life, energy density, temperature range and environmental protection.

This product specification describes the type, size, structure, electrochemistry performance, service life, and BMS characteristics.

Long cycle life
Ultra low self discharge
More usable capacity
BMS Protection
Fast Charging
Light weight
Increased flexibility
Easy installation
Environment friendly

Basic information Of LFP Energe Storage Battery :

Model	FP05-4U	FP05-4U	FP05-4U	FP05-4U	FP05-4U
Battery Type	LiFePO4	LiFePO4	LiFePO4	LiFePO4	LiFePO4
Energy	6.912KWh	13.824KWh	20.736KWh	27.648KWh	34.56KWh
Capacity	100AH	200AH	300AH	400AH	500AH
Rated Voltage	51.2V	51.2V	51.2V	51.2V	51.2V
Working Voltage Range	40～58.4V	40～58.4V	40～58.4V	40～58.4V	40～58.4V
Max charge current	100A	100A	100A	100A	100A
Max discharge current	100A	100A	100A	100A	100A
DOD	100%	100%	100%	100%	100%
Max string parallel number	15	15	15	15	15
Lifecycle	6000 cycles	6000 cycles	6000 cycles	6000 cycles	6000 cycles
Operating Temperature	Charge:0~60℃Discharge:-10～60℃
Operation Humidity	5~95%	5~95%	5~95%	5~95%	5~95%
Nominal Operation Altitude	<3000m	<3000m	<3000m	<3000m	<3000m
IP Rating	IP65	IP65	IP65	IP65	IP65
Warranty period	5	5	5	5	5
Certification	MSDS UN383	MSDS UN383	MSDS UN383	MSDS UN383	MSDS UN383
Net weight	～50KG	～100KG	～150KG	～200KG	～250KG
Dimension(LWH)	574482.6177mm	574482.6177mm	574482.6177mm	574482.6177mm	522240218mm
Rack size(LWH)	5194091087mm	574482.6177mm*2	574482.6177mm*3	574482.6177mm*4	574482.6177mm*5

Main Applications Of LFP Energe Storage Battery:

This product is mainly used for Solar System,Marine/Boat/RV,Electric Vehicle,Electric Power Tools,Street Solar Lights and so on.

51.2V LiFePO4 Battery Pack 6000 Cycles Rack Lifepo4 Battery Module

FAQ:

Q1: Are yocu fatory?

A: Yes, we are professional manufacturer for polymer batteries since 2017.
Q2: When you ship my order?
A: Normally 35-45days after payment confirmed, but it can be negotiated based on order qty and production schedule.
Q3: Can I get the pre-production sample?
A: Yes, we will send you sample for approval first, after you confirm, then we will start mass production order.
Q4: Can battery size customized available?
A: Yes, Please send up the capacity and max battery size, so that we can search our model for you.

Q5: Where can I get the price?

A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we’ll regard your inquiry priority.

51.2V LiFePO4 Battery Pack 6000 Cycles Rack Lifepo4 Battery Module
