    1S1P 3.85V 1200mAh Lithium Ion Battery Pack For Wearable Device Embedded

    Ask Lasest Price
    Brand Name : FUNPACK
    Model Number : APP00367 3.85V
    Certification : CE UL ROHS REACH
    Price : Negotiated The Price
    Payment Terms : T/T, D/P, D/A, L/C
    Supply Ability : 5000PCS /Day
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    1S1P 3.85V 1200mAh Lithium Ion Battery Pack For Wearable Device Embedded

    Long Life Li-ion Polymer Battery For Intelligent Wearable Device 3.85V 1200mAh


    Product Description:

    This is our newly designed polymer battery pack. With the latest structural design, the battery capacity of 1200mAh

    is made in a very small size, which is suitable for the internal layout of various small-size electronic products. Battery can also be used in medical products and wearable products, and is suitable for various Bluetooth headset trackers, etc.


    Product Parameters:

    ItemSpecification
    Battery Pack Type1S1P Embedded
    Cell Type1S1P
    Capacity1200mAh(min)
    Standard Current240mA(0.2C)
    Maximum Charging Current
    Charge Voltage 4.4V@ 0 ~ 20, cut off 24mA Recharge trigger voltage: 4.2V240mA (0.2C)
    Charge Voltage 4.4V@21 ~ 45, cut off 24mA Recharge trigger voltage: 4.2V1200mA (1.0C)
    Charge Voltage 4.3V@46 ~ 55, cut off 24mA600mA (0.5C)
    Pre-Charge Voltage 3.0V@ 0 ~ 55240mA (0.2C)
    Maximum Discharging
    Discharge Current – @ -20 ~ 101200mA (1.0C)
    Discharge Current – @ 10 ~ 602400mA(2.0C)
    Nominal Voltage3.85V
    Suggestive Discharge Cut off Voltage
    Discharge End of Voltage for Device set up3.2V ~ 3.4V
    End of Voltage (Discharge SOC = 0%)3.0V
    Cycle lifeAfter 500 cycles (Under 23±2 )
    Operating Temperature
    and Humidity Range
    Charge: 0 ~ 60 Humidity: Less than 85% RH
    Discharge: -20 ~ 60 Humidity: Less than 85% RH
    Storage Temperature and Humidity Range
    When stored within 1 Month (3.7V ~ 3.9V)-20~ +60
    When stored within 3 Month (3.7V ~ 3.9V)-20~ +30
    When stored within 12 Month (3.7V ~ 3.9V)-20~ +25
    Impedance< 150mΩ
    Shipment Voltage3.75V ~ 4.0V
    NTCNTC 100K, Bv:4250K

    PCM:

    ItemSpecificationParameterUnit
    Operating Temperature25
    Over Charge Voltage ProtectDetect Voltage4.475±0.02V
    Delay Time0.7~1.3Sec
    Release4.475±0.02V
    2nd Over Charge Voltage ProtectDetect Voltage4.55±0.02V
    Delay Time0.55~2.0Sec
    Release4.35±0.05V
    Over Discharge Voltage ProtectDetect Voltage2.8±0.035V
    Delay Time14~26mSec
    Release3.0±0.035----
    2nd Over Discharge Voltage ProtectDetect Voltage2.5±0.05V
    Delay Time32~128mSec
    Release2.9±0.05----
    Over Charge Current ProtectDetect Current2.125~2.875A
    Delay Time11~21mSec
    ReleaseDisconnect Charger---
    2nd Over Charge Current ProtectDetect Current1.96~3.15A
    Delay Time8.8~32mSec
    ReleaseDisconnect Charger---
    Over Discharge Current ProtectDetect Current2.8~3.8A
    Delay Time8~16mSec
    ReleaseRemove R-Load or Connect Charger---
    2nd Over Discharge Current ProtectDetect Current2.5~3.8A
    Delay Time8~16mSec
    ReleaseRemove R-Load or Connect Charger---
    Short CircuitDetect CurrentExternal ShortA
    Delay Time175~400μSec
    ReleaseRemove R-Load or Connect Charger---
    2nd Short CircuitDetect CurrentExternal ShortA
    Delay Time196~364μSec
    ReleaseRemove R-Load or Connect Charger---
    Power Consumption
    Operating Mode12.0 (max)μA
    Power Down Mode0.5(max)

    μA



    Main Applications :

    It is suitable for automobile remote control, electronic dictionary, electronic watch, electronic toys, electronic clock, electronic

    health scale, blood glucose meter, electronic thermometer, calculator, TIntelligent voice speaker and electronic dictionary

    and translatorand other small household appliances


    FAQ:

    Q1: Can I have a sample order?
    A:
    Yes, we welcome sample order to test and check quality. Customized is available.
    Q2: What about the lead time?
    A: Sample needs 7-12 days, mass production time needs negotiation.
    Q3: How do you ship the goods and how long does it take to arrive?
    A: We usually ship by JEC. It usually takes 13-15 days to arrive. Airline and sea shipping also optional.
    Q4: How to proceed an order?
    A: Firstly let us know your requirements or application. Secondly we quote according to your requirements or our
    suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly we arrange the production.
    Q5: Is it OK to print my logo on product?
    A: OK, Need customer provide their packaging or we make neutral packaging.
    Q6: Where can I get the price?
    A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us

    or tell us in your email so that we’ll regard your inquiry priority
