3.8V 5300mAh High Capacity Lithium ion Polymer Battery For Wireless
WiFi Device
Features:
Worldwide approvals and certification of safety standards
Life expectancy: Up to 80% of initial capacity after 500 cycles
Lithium Polymer battery can provide a certain amount of electric
energy to drive their functions
of signal transmission or data acquisition. And Lithium Polymer
secondary battery allows charging and discharging
cycle, broadening the servicing life of electronics products.
effectively avoiding the over-charge, and short circuit.
High Capacity with Small Size
Basic specification:
| Item | Specification |
| Battery Pack Type | 1S1P Removable |
| Capacity | 5300mAh(typ.)
5260mAh(min) |
| Standard Current | 1052mA (0.2C) |
| Maximum Charging Current |
| Charge current 4.35V@ 0℃ ~ 15℃, cut off 105.2mA Maintenance trigger voltage: 4.2V | 1052mA (0.2C) |
| Charge current 4.35V@15℃ ~ 45℃, cut off 105.2mA Maintenance trigger voltage: 4.25V | 2360mA (0.5C) |
| Charge current 4.2V@45℃ ~ 60℃, cut off 105.2mA Maintenance trigger voltage: 4.0V | 2360mA (0.5C) |
| Charge current 3.0V@ 5℃ ~ 45℃, cut off 105.2mA Maintenance trigger voltage: 4.0V | 105.2mA (0.05C) |
| Maximum Discharging Current | |
| Discharge Current – @ -20℃ ~ 0℃ | 1052mA (0.2C) |
| Discharge Current – @ 0℃ ~ 60℃ | 4000mA(0.76C) |
| Nominal Voltage | 3.8V |
| Cut-off Voltage | 3.0V |
| Cycle life | After 500 cycles (Under 23±2 ℃) |
Environmental using
conditions | |
| When stored within 1 Month (RSOC 50%) | -20~ +45℃ |
| When stored within 3 Months (RSOC 50%) | -20~ +35℃ |
| When stored within 12Months (RSOC 50%) | -20~ +25℃ |
| Impedance | about＜100mΩ |
| Weight | ≤ 110g |
| Shipment Voltage | 3.75V ~ 3.9V |
| NTC | NTC 10K , Bv:3435K |
PCM:
| Item | Specification | Parameter | Unit |
| Operating Temperature | | 25 | ℃ |
| Over Charge Voltage Protect | Detect Voltage | 4.425±0.025 | V |
| Delay Time | 1 | Sec |
| Release | 4.425 | V |
| Over Discharge Voltage Protect | Detect Voltage | 2.4±0.035 | V |
| Delay Time | 32 | mSec |
| Release | 2.4 | ---- |
| Over Charge Current Protect | Detect Current | 3.11~4.21 | A |
| Delay Time | 8 | mSec |
| Release | Disconnect Charger | --- |
| Over Discharge Current Protect | Detect Current | 4.81~6.51 | A |
| Delay Time | 8 | mSec |
| Release | Charge Release | --- |
| Short Circuit | Detect Current | External Short | A |
| Delay Time | 280 | μSec |
| Release | Under Detect Current | --- |
| Power Consumption | | | |
| Operating Mode | | 6.0 (max) | μA |
| Power Down Mode | | 0.5(max) | μA |
Main Functions:
For safety devices,such as cellular phone, interphone, cordless
phone,digital camera, portable DVD, portable television,
GPS, PDA, PMP, PSP, portable medical device, instrument and
apparatus,miner lamp, searchlight, lighting devices, ect.
FAQ:
Q: Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Customized is available.
Q: What about the lead time?
A: Sample needs 7-12 days, mass production time needs negotiation.
Q: How do you ship the goods and how long does it take to arrive?
A: We usually ship by JEC. It usually takes 13-15 days to arrive.
Airline and sea shipping also optional.
Q: How to proceed an order?
A: Firstly let us know your requirements or application. Secondly
we quote according to your requirements or our
suggestions.Thirdly customer confirms the samples and places
deposit for formal order. Fourthly we arrange
the production.
Q: Is it OK to print my logo on product?
A: OK, Need customer provide their packaging or we make neutral
packaging.
Q: Where can I get the price?
A: We usually quote within 24 hours after we get your inquiry. If
you are very urgent to get the price, please call us or tell us
in your email so that we’ll regard your inquiry priority
