Product Description
Middle Size Dual View X-ray Baggage and Luggage Inspection Scanner
for Public Security Scanning.
We have three different designs for your option, all patents and
copyrights reserved.
Now dual view x-ray security scanner is a hot trend for high end
customers security needs, it is deployed with two generator, one is
from top, the other from the side, which can give two perspective
and high quality scanned images from different angles, to discover
and reveal the potential threads in the baggages and luggages.
Specification
| Item | Definition | Specs |
| System Parameters | Size | 1350(L)x1250(W)x1700(H)mm |
| Weight | 1900kg |
| Power | 220AC/50Hz |
| Power Consumption | 1.6kW |
| X-ray Tube | Type | Closed |
| Max.Voltage | 130kV |
| Max.Power | 40W |
| Spot Size | 7μm |
| X-ray System | Intensifier | FPD |
| Monitor | 22 ‘’LCD |
| System Magnification | 1600 X |
| Detection Region | Max.Loading Size | Φ570mm |
| Max.Inspection Area | 450mm x 450mm |
| X-ray Leakage | <1μSv/h |
Advantages
1,Comprehensive leadership: Product performance of International
first-class level, high-definition images, strong penetration, high
resolution, and powerful material identification.
2,Unique system: with embedded windows operating system, multi-core
ARM, the system features a simple architecture, low power
consumption, energy saving and environmentally friendly, meanwhile
it has a real-time status monitoring function to keep abreast of
the device work process.
3,Safety and environmentally friendly: The equipment meets safety
and environmental standards.
4,Stable and reliable: The production process is strictly
controlled in accordance with the IS09001 quality management
system. Through rigorous high-low temperature experiments, wet heat
experiments and vibration experiments, it is certified that the
product runs continuously for more than 10,000 hours without
failure.
5,Strong frame shell: Made by 304 stainless steel, 2-3mm
cold-rolled steel plate and Fangtong steel, integrated with
industrial advanced technology, the frame shell outside is designed
with strong and reliable structure, to ensure rust-proof,
corrosion-proof and free of cable damage
Equipment functions
1,Imaging process functions: Color/BW, Local Enhancement,
Enhancement of High Penetrating Power, Enhancement of low
Penetrating Power, Super Enhancement, Organics Exclusion, Inorganic
Exclusion, Negative, Brightening, Darkening, Gray-Level scan, Zoom
in and out, Pseudo-color Processing, Organics Enhancement, Alarm
sign box of suspicious object, Edge Enhancement.
2,System functions: Power-on self-test, multi-level user
management, image management, TIP management, curve diagnosis,
keyboard diagnosis, device information query, multi-format image
export, OSD operation function, image mirroring, 1-64 times
continuous magnification, magnifying glass, Operator training,
accurate positioning of package images, empty channel reminders,
remote operation software, one-button shutdown, and intelligent
roller engine (optional).
